DC 12/24V 16.67A 200W led switching power supply


Product Specification:

  • Item Type: YJ200-W1V12
  • Lamp Power(W): 200W
  • IP Rating: IP22
  • Input Voltage(V): AC 100V-240V
  • Warranty(Years): 2
see price

DC 12/24V 16.67A 200W led switching power supply

200W led switching power supply DC12/24v Model No: YJ200-W1V12
Power: 200W
size: 160*98.3*49.3mm
IP Degree: IP22
Input voltage: AC 100-240V
Output voltage: DC 12/24V
Output current: 16.67/8.33A





1. AC input range selectable by switch.

2. Protections: Short circuit / Overload / Over voltage / Over temperature.

3. Forced air cooling by built-in DC fan.

4. Withstand 300vac surge input for 5 second.

5. Built-in cooling Fan ON-OFF control.

6. Built-in constant current limiting circuit.

7. LED indicator for power on.

8. Fixed switching frequency at 90KHz.

9. Low cost, high reliability.

10. 2 years warranty.
